DYTRAN 3055系列通用加速度计

发布时间：2021-04-13 16:56:54 浏览：1597

DYTRAN 3055系列是一款经济实惠合理有效的单轴IEPE加速度计，灵敏度为10~500mV/g。DYTRAN 3055系列通用型加速度计具备TEDS功能模块。

DYTRAN 3055系列通用型加速度计是由封装形式在实心钛壳中的陶瓷剪截传感元器件、10-32径向连接器和10-32螺柱安装能力构成的。DYTRAN 3055系列通用型加速度计依托于隔离，避免EMI/接地回路干扰，集成低噪声JFET电子元器件。该装置还密封性，在高湿度和肮脏环境下获取可靠性能。

特点：

钛

密封性

基地隔离

TEDS选项

IEPE

应用领域：

模态与结构分析

振动控制

一般高温振动监测

深圳市开云电竞创展科技有限公司，优势渠道提供DYTRAN传感器产品，欢迎咨询。

详情了解DYTRAN请点击：/brand/52.html

或联系我们的销售工程师：0755-83642657 QQ: 2295048674


MODEL	SPECIFICATIONS
3055D1T	10 mV/g sensitivity, 500g range, 10–32 radial connector, 10–32 tapped hole, 10 grams,–67 to +250°F Operation
3055D1T	10 mV/g sensitivity, 500g range, 10–32 radial connector, 10–32 tapped hole, 10 grams,–60 to +250°F Operation,–40 to +185°F TEDS Operation
3055D2	100 mV/g sensitivity, 50g range, 10–32 radial connector, 10–32 tapped hole, 10 grams,–67 to +250°F Operation
3055D2T	100 mV/g sensitivity, 50g range, 10–32 radial connector, 10–32 tapped hole, 10 grams,–60 to +250°F Operation,–40 to +185°F TEDS Operation
3055D3	500 mV/g sensitivity, 10g range, 10–32 radial connector, 10–32 tapped hole, 10 grams,–67 to +225°F Operation
3055D3T	500 mV/g sensitivity, 10g range, 10–32 radial connector, 10–32 tapped hole, 10 grams,–60 to +225°F Operation,–40 to +185°F TEDS Operation
3055D4	50 mV/g sensitivity, 100g range, 10–32 radial connector, 10–32 tapped hole, 10 grams,–67 to +250°F Operation
3055D4T	50 mV/g sensitivity, 100g range, 10–32 radial connector, 10–32 tapped hole, 10 grams,–60 to +250°F Operation,–40 to +185°F TEDS Operation
3055D5	20 mV/g sensitivity, 250g range, 10–32 radial connector, 10–32 tapped hole, 10 grams,–67 to +250°F Operation
3055D5T	20 mV/g sensitivity, 250g range, 10–32 radial connector, 10–32 tapped hole, 10 grams,–60 to +225°F Operation,–40 to +185°F TEDS Operation
3055D6	200 mV/g sensitivity, 25g range, 10–32 radial connector, 10–32 tapped hole, 10 grams,–67 to +225°F Operation
3055D6T	200 mV/g sensitivity, 25g range, 10–32 radial connector, 10–32 tapped hole, 10 grams,–60 to +225°F Operation,–40 to +185°F TEDS Operation
